Section 5.30

Pitman Arm, Tie Rods & Track Rods

Tie Rod Puller

CT3015

Pitman Arm and Tie Rod Puller

Tie Rod / Pitman Arm Puller
Opening size - 27mm
Pull travel - 54mm

Tie Rod Puller
t Click picture for more information
Pitman Arm Puller

CT3014

Pitman Arm Puller

Pitman Arm Puller
Opening size - 33mm
Pull travel 63mm
Fits most cars and vans

Pitman Arm Puller
t Click picture for more information
Power Steering Pump Pulley Kit

CT3616

Power Steering Pump Pulley Kit

Power Steering Pump Pulley Kit
For Ford | Chrysler and GM vehicles
With Saginaw / Thompson/ Ford C111
and C2 power steering pumps.
Fits many pulley hub diameters including
engines with a metric shaft.

Power Steering Pump Pulley Kit
t Click picture for more information
Transmission Servicing

CT3183

Axle Joint Tool 28-35mm

Steering Arm Removal Tool - 28 / 35mm
Track Rod End Remover
27mm Hex or 1/2in Drive /400mm Long
Suitabe for most European vehicles

Transmission Servicing
t Click picture for more information
Transmission Servicing

CT3182

Axle Joint Tool 35-45mm

Steering Arm Removal Tool - 35 / 45mm
Track Rod End Remover
27mm Hex or 1/2in Drive /400mm Long
Suitabe for most European vehicles

Transmission Servicing
t Click picture for more information
Steering Knuckle Pinch-Bolt Drift

CT4404

Steering Knuckle Pinch-Bolt Drift

3pc VAG Steering Knuckle Pinch-bolt Drift
for use when 9-10mm drift is required
on VAG vehicles with 4 link suspension.
Applicable to Audi A4 / A6 and Volkswagen Passat.
For use with a vibrating air hammer or air chisel.
The drift length is designed for ease of access
and the removal operation is in three stages.

Steering Knuckle Pinch-Bolt Drift
t Click picture for more information
Universal Steering Knuckle Set

CT3592

Universal Steering Knuckle Set - 7pc

7pc Universal Steering Knuckle Set
Enables the servicing of struts and ball joints
with aluminium or cast iron knuckles
and centralized and non-centralized slots.
13mm Hex Drive Knuckle Spreader
8 | 10 | 12mm Guide Pins
5 and 8mm deep Spreader Inserts
Hexagonal Key

Universal Steering Knuckle Set
t Click picture for more information
Steering Rack Wrench

CT3739

Steering Rack Wrench

Rack Wrench - 1/2in.Dr
25 - 55mm Heavy Duty Steering Rack Tie Rod Wrench
Use to service all inner tie rod ends.
Prevents damage to rack components.
Use for removal or installation.
Clamp force increases as load is applied.
Suits multiple rack ends and sizes.

Steering Rack Wrench
t Click picture for more information
Steering Wheel Lock Plate Tool

CT3022

Steering Wheel Lock Plate Tool

Steering Wheel Lock Plate Remover
Ideal for detaching steering column lock plates on the majority of cars with air bags
1-9/16in. x 18mm and 14 x 1.5mm adaptor

Steering Wheel Lock Plate Tool
t Click picture for more information
Tie Rod or Pitman Arm Set

CT3369

Tie Rod / Pitman Arm Set

5pc Tie Rod / Pitman Arm Adjustment Set
1/2in.Dr Suitable for cars / vans and trucks.
Sizes : 3/4 | 7/8 | 9/8 | 23/16 | 29/16in.
Allows 360 degree rotation of adjusting sleeve in tight areas.

Tie Rod or Pitman Arm Set
t Click picture for more information
Tie Rod Puller

CT3250

Tie Rod Puller

Tie Rod Puller for use on Front wheel drive vehicles with rack and pinion steering

Tie Rod Puller
t Click picture for more information
Inner Tie Rod Service Kit

CT3577

Inner Tie Rod Service Kit

Inner Tie Rod Installer / Remover Tool Set
For inner tie rods that are inaccessible to adjust with a normal spanner.
The long 1/2in.Dr socket is used with the Crowfoot drivers supplied
sizes - 1-3/16 | 1-1/4 | 1-5/16 | 1-7/16 | 14 | 17 | 33.6mm
Suits all rack and pinion mitsubishi vehicles

Inner Tie Rod Service Kit
t Click picture for more information
Tie Rod Wrench - 1/2in.Dr

CT3913

Tie Rod Wrench - 1/2in.Dr

Universal Tie Rod Wrench - 1/2in.Dr
Range from 27mm to 42mm
Easily removes inner tie rod ends without dissassembling rack and pinion

Tie Rod Wrench - 1/2in.Dr
t Click picture for more information
Inner Tie Rod Tool / Wrench

CT4012

Inner Tie Rod Tool - Multi-purpose

Multi-Purpose Inner Tie Rod Tool
Compatible with 1/2in.Dr tool.
Use to replace the inner tie rod ends
without replacing the rack and pinion.
Capacity : 33 - 42mm

Inner Tie Rod Tool / Wrench
t Click picture for more information
Track Rod End Remover

CT3383

Track Rod End Remover

4pc Track Rod Set
For the removal and replacement of the inner steering ball joint
without the need to dismantle the steering rack from the bulkhead.
Drive Head Range -
30 - 35mm diameter
35 - 40mm diameter
40 - 45mm diameter

Track Rod End Remover
t Click picture for more information
Tie Rod Service Set

CT3881

Track Rod Setting Tool Kit

Tie Rod Service Set
For tie rod servicing without additional alignment
Reduces the workload when changing tie rods.
For replacement of defective tie rod head.
Allows precise adjustment of new joint

Tie Rod Service Set
t Click picture for more information
