Section 5.8

Camshaft / Crankshaft - Belt, Pump and Pulley Tools

VAG Camshaft Adapter Socket

CT4752

Camshaft Adapter Socket - VAG

VAG Camshaft Adapter Socket
3/8in. Drive / S45C Steel.
Use to rotate and hold the intake camshaft during timing chain service
on 4 cylinder 1.8L and 2.0L TFSi generation III direct injection engines.

VAG Camshaft Adapter Socket
t Click picture for more information
Pump Pulley Remover - VAG

CT4763

Pump Pulley Remover - VAG

VAG Pump Pulley Remover
For the removal of the high pressure pump hub
on 1.6L and 2.0L TDi common rail diesel engines.
VW OEM : T40064

Pump Pulley Remover - VAG
t Click picture for more information
Elastic Ribbed Belt Tool Kit

CT2938

Elastic Ribbed Belt Tool Kit

Elastic Ribbed Belt Tool Kit
For the quick and easy removal and installation of Elastic Ribbed Belts
fitted to modern auxiliary drive systems
such as the alternator or power steering.
Suitable for most vehicle makes and models

Elastic Ribbed Belt Tool Kit
t Click picture for more information
Stretch Belt Tool Set

CT4846

Stretch Belt Tool Set - 2pc

2pc Stretch Belt Tool Set
Universal tool set for fitting stretch belts to modern vehicles.

Stretch Belt Tool Set
t Click picture for more information
Auxiliary Stretch Belt Removal Tool

CT4623

Auxiliary Stretch Belt Removal Tool

Auxiliary Stretch Belt Removal Tool
BMW | Chrysler | Citroen | Fiat | Ford |
Iveco | Mazda | Mercedes | Peugeot | Volvo

Auxiliary Stretch Belt Removal Tool
t Click picture for more information
Alternator Stretch Belt Tool Kit

CT3953

Alternator Stretch Belt Tool Kit

Alternator Stretch Belt Tool Kit
For Mounting and Dismounting Alternator Stretch Belts
without Damaging Pulleys and Belts.
With Belt Installers - 32 | 45 | 50mm Diameter
Belt Remover
Self Locking Nut / M8 Fixing Nut and Screws -
M8 x 25 - 5.9mm D
M8 x 40 - 5.7mm D
M8 x 53 - 5.7mm D
M8 x 65 - 5.6mm D Short and Long

Alternator Stretch Belt Tool Kit
t Click picture for more information
Universal Stretch Belt Tool Kit

CT4428

Universal Stretch Belt Tool Kit

Universal Stretch Belt Tool Kit
For use mainly on 1.4 and 1.6 petrol engines
when the double width crankshaft puller restricts access
preventing the belt from being removed or installed.
Use with a 17mm socket.

Universal Stretch Belt Tool Kit
t Click picture for more information
Damper Pulley Wrench Set

CT2104

Damper Pulley Wrench Set

5pc Damper Pulley Holding Wrench Set
18in. / 460mm Long Wrenches
Sizes - 13. 15. 16. 17. 19mm

Damper Pulley Wrench Set
t Click picture for more information
BMW Fan Clutch Wrench and Holder

CT4074

Fan Clutch Nut Wrench - 32mm BMW

32mm Fan Clutch Nut Wrench
BMW Water Pump Removal Tool Kit
32mm Fan Clutch Wrench
Double-ended Water Pump Fan Pulley Holder
For removing water pumps on models with
temperature dependent viscosity drive fans.
Removes lock nuts on thermo-Viscous fans.

BMW Fan Clutch Wrench and Holder
t Click picture for more information
Fan Hub Tool Spanner

CT2075

Fan Hub Holding Tool / Spanner

2pc Viscous Fan Spanner with Fan Hub Holding Tool Set

Fan Hub Tool Spanner
t Click picture for more information
10pc Fan Clutch Wrench Set

CT3907

Fan Clutch Wrench Set - 10pc

10pc Fan Clutch Wrench Set
With Fan Pulley Holding Tools
Fan Clutch / Nut / Hub Wrenches
Range from 37mm to 83mm
Range from 1-7/16 to 3-1/4in.

10pc Fan Clutch Wrench Set
t Click picture for more information
Fan Clutch Tool Set

CT3600

Fan Clutch Tool Set

Fan Clutch Tool Set
Removes thermo viscous fan lock nuts on
Mercedes-Benz | BMW and many Ford models.
Allows the water pump pulley to be held in place
while loosening the radiator fan for removal.
Clutch Wrenches - 32 | 36 | 40 | 65mm
Fan Clutch Holding Wrench - 38mm | 44.5mm

Fan Clutch Tool Set
t Click picture for more information
Pulley Puller

CT3016

Pulley Puller

Heavy Duty Pulley Puller
Adjustable Jaw Tension
Pulls pressed-on 1 and 2 groove pulleys
For Alternators and Power Steering Pumps / also Alternator Bearings

Pulley Puller
t Click picture for more information
Camshaft and Crankshaft Pulley Holder

CT3917

Camshaft and Crankshaft Pulley Holder

Universal Camshaft and Crankshaft Pulley Holder
Holds camshaft or diesel pump sprockets and gears
for removal and tightening of retaining bolts.
Interchangeable pins : 3.5 | 4 | 4.5 | 5 | 6 | 7 and 10mm.
Wrench swivels to adjust from 32 - 127mm
1/2in.Dr for use with ratchets or power bars.

Camshaft and Crankshaft Pulley Holder
t Click picture for more information
Mini Cooper Pulley Holding Tool

CT4178

Camshaft Belt Pulley Tool - Mini

Camshaft Belt Pulley Tool
Mini Cooper Serpentine Belt Tool - R50 / R53
For loosening the camshaft pulley then using the
pin to lock the camshaft pulley tensioner in place
allowing the removal and replacement of the timing belt.
Applicable : BMW Mini Cooper - R50 / R53
BMW engine W10/W11

Mini Cooper Pulley Holding Tool
t Click picture for more information
Universal Pulley Puller

CT4632

Pulley Puller - Adjustable

Adjustable Timing Pulley Puller
This tool is designed for removing drive pulleys with face grooves.
Removes pulleys without risk of damage.
Adjustable Legs for different pulley diameters.
For removing pulleys with 3 | 6 | 9 slots.

Universal Pulley Puller
t Click picture for more information
Universal Pulley Puller

CT4400

Pulley Puller - Unversal

Universal Pulley Puller
18mm pulling legs.
8 Slots for holding pulling legs in different positions.
16mm Diameter spindle with cantering ball.
Use with 24mm Socket or Spanner.
Draws pulley by the holes without causing damage.
Movable legs adapt to different pulley diameters.
Suitable for different bolt patterns and distances.

Universal Pulley Puller
t Click picture for more information
Camshaft Pulley Puller

CT4633

Pulley Puller - VW R2 / T4 / A3

VW R2/T4/A3 Camshaft Pulley Puller
Ideal for removing rusted or seized pulleys.
For in-situ car maintenance.
Adjustable legs fit different diameters of pulley.
VW T4 use six hook
AUDI A3 use five hook
R2 use six hook

Camshaft Pulley Puller
t Click picture for more information
Puller Removal and Installation Set

CT2579

Pulley Puller and Installer Set

Pulley Puller and Installer Set
Removes pressed-on alternator and power steering pulleys
For late model GM / Ford and Chrysler engines
Adapters for Quad 4 engines
Adapters for Ford modular engines

Puller Removal and Installation Set
t Click picture for more information
Mini Cooper Pulley Holding Tool

CT4179

Camshaft Belt Pulley Tool - Mini

Camshaft Belt Pulley Tool
Mini Cooper Serpentine Belt Tool
For loosening the camshaft pulley then using the
pin to lock the camshaft pulley tensioner in place
allowing the removal and replacement of the timing belt. br> Applicable : BMW Mini Cooper engine S/W11

Mini Cooper Pulley Holding Tool
t Click picture for more information
Puller for Drive Pulley

CT3185

Puller for Ribbed Drive Pulley

Puller for Ribbed Drive Pulleys
Length - 200mm | Height - 80mm
Low Profile suitable for most vehicles
Knurled Screws - included
Hex Keys

Puller for Drive Pulley
t Click picture for more information
Pulley Holding Tool

CT3028

Pulley Holding Tool

Pulley Holding Tool
For holding pulleys in place and preventing movement
Suitable for Crankshafts and Camshafts

Pulley Holding Tool
t Click picture for more information
Tension Pulley Wrench

CT4406

Cambelt Pulley Holder

VAG Cambelt Pulley Holder
For VW 1.4 / 1.6 / 2.0 litre engines
Also for 4 valve engines with pin diameter 11.5 mm
and counter holding the belt pulley of 2 valve engines.
Applicable to : Audi / Skoda / VW vehicles

Tension Pulley Wrench
t Click picture for more information
Strap Wrench

CT1246

Strap Wrench - Groove

Strap Wrench Groove Type Belt for Pulley Removing

Strap Wrench
t Click picture for more information
Strap Wrench

CT1245

Strap Wrench - Tooth

Strap Wrench Tooth Type Belt for Pulley Removing

Strap Wrench
t Click picture for more information
Master Cam Clamp Set

CT3896

Cam Clamp Set - 5pc

5pc Master Cam Clamp Kit
This universal kit reduces repair time and covers
most Single / Twin and Quad cam engines.
Locks camshafts during belt replacement.
Prevents engine damage due to incorrect timing.
Allows easy operation in small engine bays.

Master Cam Clamp Set
t Click picture for more information
Timing Belt Extension Tool - 1/4in.Dr

CT3944

Timing Belt Extension Tool - 1/4in.Dr

1/4in.Dr Timing Belt Extension Tool
Range 8mm - 25mm
With 3mm Chrome-Vanadium Pins

Timing Belt Extension Tool - 1/4in.Dr
t Click picture for more information
Timing Gear Puller

CT3018

Timing Gear Puller

Timing Gear Puller
Removes Timing Gears and other gears with tapered holes

Timing Gear Puller
t Click picture for more information
Belt Installation Tool

CT1515

Belt Installation Tool

Belt Installation Tool
For Restricted Access to V style Timing Belts
600mm Reach

Belt Installation Tool
t Click picture for more information
Cambelt Tension Gauge

CT1597

Cambelt Tension Gauge

Cambelt Tension Gauge
Precise Measurement
Universal - Suitable for Cambelts of various widths
Dual Direction Rotating Scales with Clear Incremental Markings

Cambelt Tension Gauge
t Click picture for more information
Mercedes V-Belt Tensioning Tool

CT4635

Ribbed Belt Mounting Lever

Mercedes V-Belt Tensioning Tool
For setting the tension wheel and fitting the ribbed belt.
Suitable for Mercedes models : 168 | 169 A-Class | 245 B-Class
Length : 620 mm
Size : 15mm

Mercedes V-Belt Tensioning Tool
t Click picture for more information
Timing Belt Setting Tool Kit

CT1516

Timing Belt Setting Tool Kit

Timing Belt Tension Setting Tool Kit
for engine compartments with restricted access.
Ideal for releasing tension on serpentine belts.
Suitable for most vehicles.
3/8in.Dr x 580mm Long with 1/2in.Dr extension
3/8in.Dr Crowfoot Wrenches : 13 | 14 | 15mm
3/8in.Dr Sockets : 15 | 16 | 18mm

Timing Belt Setting Tool Kit
t Click picture for more information
Cam Belt Tension Wrench Set

CT4017

Cambelt Tension Wrench Set - 5pc

5pc Cambelt Tension Pulley Wrench Set
E-Star Sizes : E10 | E12 | E14 | E16 | E18
For biasing the auxiliary belt tension off and on
during installation of the belt in the vehicle.
Slim curved handle for use in confined spaces.

Cam Belt Tension Wrench Set
t Click picture for more information
Tensioner Pulley Wrench Set

CT4018

Cambelt Tension Wrench Set - 15pc

15pc Cambelt Tension Wrench Set
With Interchangeable Heads
for tensioners on auxiliary and timing pulleys.
Includes bar with locking system.
Star : E10 | E12 | E14 | E16 | E18
Sizes : 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19mm

Tensioner Pulley Wrench Set
t Click picture for more information
Cambelt Tension Wrench Set

CT3449

Cambelt Tension Wrench Set 9pc

9pc Cambelt Tension Wrench Set
with Interchangeable Heads
For tensioners on auxiliary and timing pulleys
Sizes : 12 to 19mm
Includes bar with locking system.

Cambelt Tension Wrench Set
t Click picture for more information
Belt Tensioner Retaining Pins

CT3665

Belt Tensioner Retaining Pins

6 Belt Tensioner Retaining Pins
For use on Automatic Belt Tension Systems in vehicle engines.

Belt Tensioner Retaining Pins
t Click picture for more information
BMW Oil Seal Kit

CT4427

Crankshaft Oil Seal Removal Kit - BMW

BMW Crankshaft Oil Seal Kit
For removal and installation of the rear crankshaft oil seal.
Applicable to :
N40 | N42 | N45 | N45T | N46 | N46T | N52 | N53 | N54.

BMW Oil Seal Kit
t Click picture for more information
Camshaft and Crankshaft Seal Kit

CT3690

Camshaft and Crankshaft Seal Kit

Citroen / Peugeot Petrol Engine Camshaft and Crankshaft Seal Installer Kit
Citroen / Peugeot Petrol 1900-2000

Camshaft and Crankshaft Seal Kit
t Click picture for more information
Camshaft Seal Kit

CT3149

Crankshaft and Camshaft Seal Kit

Crankshaft and Camshaft Seal Remover and Installation Kit
Includes 2 Seal removers for multiple applications
Angled blades for removing seals in limited access

Camshaft Seal Kit
t Click picture for more information
Crankshaft Seal Remover / Installer Kit

CT3150

Crankshaft Seal Remover / Installer Kit

Crankshaft Seal Remover / Installer Kit
Seal sizes - 27mm and 58mm in diameter.
Universal covering a wide range of vehicles.
Use the existing bolt in the vehicle for installation.
Screw-type adapter to aid cantering the seal.
With Aluminium Blue Seal Adapters to prevent crank damage.

Crankshaft Seal Remover / Installer Kit
t Click picture for more information
BMW Harmonic Balance Tool

CT4333

Crankshaft Harmonic Balance Tool - BMW

BMW Crankshaft Harmonic Balance Tool
for E39 | E46 | E60 | E61 | E81 | E83 | E90 | E91 engines
Holds vibration damper when loosening and tightening centre crankshaft bolt.

BMW Harmonic Balance Tool
t Click picture for more information
Harmonic Balance Puller Set

CT3919

Harmonic Balance Puller Set

Universal Harmonic Balance Puller
Installation and Removal Tool Kit
with Puller Plate and 4 sets of 3 screws
Centre bolt 10mm and 9 adaptors
For use on the crank pulley damper /
crankshaft damper / torsion damper
or vibration damper for drive belts

Harmonic Balance Puller Set
t Click picture for more information
Harmonic Balancer Puller Set

CT3021

Harmonic Balance Puller Set

Removes Harmonic Balances | Gear Pulleys
Steering Wheels and Crank Shaft Pulleys
Yoke allows 2 or 3 hole application
Alloy steel centre screw with floating removable swivel
Assorted Bolts

Harmonic Balancer Puller Set
t Click picture for more information
Harmonic Balance Puller Set

CT1922

Harmonic Balance Puller Set

46pc Harmonic Balance Puller Set
Removes Harmonic Balancers / Gear Pulleys /
Steering Wheels and Crank Shaft Pulleys
Zinc Plated Yoke and Bolts
5in. Pressure Screw
Small Cantering Adaptor
Large Cantering Adaptor
Flat Shaft Adaptor

Harmonic Balance Puller Set
t Click picture for more information
Ford Camshaft Sprocket Puller

CT3918

Camshaft Sprocket Puller - Ford

Ford Camshaft Sprocket Puller
Size 90 x 65mm
Applicable to - F8M | F8Q | S8U | S9U
Also suitable for removing the Impeller.

Ford Camshaft Sprocket Puller
t Click picture for more information
Engine Timing Tool Pins / Locks

CT4850

Timing Tool Pins

Engine Timing Tool Set
for Ford / Mazda / PSA / Volvo
For setting engine timing when replacing the camshaft or cylinder head gasket.
Camshaft locking pin. Flywheel locking bolt
Crankshaft / high pressure pump locking pin.
PSA - Citroen / Peugeot 1.4 / 1.6 Hdi
Mazda 1.4CiTD
Ford 1.4TDCi / 1.6TDCi
Volvo 1.6D

Engine Timing Tool Pins / Locks
t Click picture for more information
Crankshaft Seal Flange Installation Tool

CT0031

Crankshaft Seal Flange Installation Tool

VW Crankshaft Seal Flange Remover and Installer
for 1.4 and 1.6 - 16 Valve VAG engines
fitted to Audi / Skoda / Fiat and VW vehicles
Specific tool vital to ensure the correct alignment
of the main seal house crankshaft sensor.
The Seal housing carries the crankshaft sensor mounting.

Crankshaft Seal Flange Installation Tool
t Click picture for more information
Crankshaft Seal Flange Installation Tool

CT4084

Crankshaft Seal Flange Installation Tool

Crankshaft Seal Flange Installation Tool - VAG Diesel
Designed to renew the crankshaft oil seal on Audi / VW vehicles
Applicable to 16V / 20V - 1.9 / 2.0 Diesel Engines since 2006.
For 4 Valve Diesel engines with integrated sender wheel.
Audi A3 4-cyl. VW Golf / Touran

Crankshaft Seal Flange Installation Tool
t Click picture for more information
VAG Crankshaft Pulley Holding Tool

CT4655

Crankshaft Pulley Holding Tool - VAG

Audi / VW Crankshaft Pulley Holding Tool
For holding the crankshaft pulley when removing or installing the crankshaft central bolt.
AUDI : A3 | A6 | Q5 2004 onwards
VW : TSI / TFSI engines with chain 1.8T | 2.0L 4V
OEM number : T10355

VAG Crankshaft Pulley Holding Tool
t Click picture for more information
VW Crankshaft Rotation Tool

CT4638

Crankshaft Rotation Tool - VAG

Unique Crankshaft Rotation Tool for VAG 5 Cylinder Engines
Necessary for crankshaft adjustment and as use as a lever.
Suitable for all 5 cylinder VW diesel engines -
VW touareg as of 2003 and transporter as of 2004
Fixing screw allows easy mounting on crankshaft.
Also found in sets : CT3394 and CT3584
VAG OEM : T10225

VW Crankshaft Rotation Tool
t Click picture for more information



Next Last

Product Search

Search Icon
Section 1 Icon Section 2 Icon Section 3 Icon Section 4 Icon Section 5 Icon Section 6 Icon Section 7 Icon Section 8 Icon Section 9 Icon Section 10 Icon

© Cannon Tools Limited  -  2017 All Rights Reserved   •  20 Station Road,  Rowley Regis,  West Midlands,  B65 0JU,  United Kingdom  |  T +44 (0) 121 561 6760
