Section 5.4

Carburettors & Fuel Injection

Copper Injector Seal Rings

CT3162

Copper Injector Seal Rings

150pc Fuel Injector Copper Seal Rings
For Diesel injector ports ( CDI ).
Sizes : 13.8 - 20.0mm External Diameter
Sizes : 7.3 - 9.4mm Internal Diameter
Depth : 1.3 - 3.0mm
10 of each size

Copper Injector Seal Rings
t Click picture for more information
Copper Injector Seal Rings

CT4675

Copper Injector Seal Rings

Injector Copper Ring Assortment
Suitable for:
Deutz / Fiat / Ford / Iveco / Kia / Land Rover
MAN / Mazda / Mercedes / Renault / Universal

Copper Injector Seal Rings
t Click picture for more information
10mm Injector Hex Bit Socket

CT4240

Hex Bit Socket 10mm 1/2in.Dr

10mm Hex Bit Socket 1/2in.Dr
Tamper Proof for Fuel Injectors

10mm Injector Hex Bit Socket
t Click picture for more information
Bosch VE Pump Sockets

CT4128

Socket Set - 3pc

3pc Socket Set with Unique Profile
for Bosch Diesel Injection Distributor Pumps
1/2in.Dr / Chrome Vanadium

Bosch VE Pump Sockets
t Click picture for more information
Bosch VE Pump Sockets

CT4028

Tri-Point Socket Set - 1/2in.Dr

Tri-Point Socket Set - 5pc 1/2in.Dr
For Triangular Profile Tamperproof Fixings
Sizes : 8 | 10 | 12 | 15 | 16.5mm
For Injection Pumps and Bosch Injectors
Applicable to VAG vehicles with TDi engines

Bosch VE Pump Sockets
t Click picture for more information
Bosch VE Pump Sockets

CT4130

Socket Set - 5pc

5pc Socket Set with unique profile for
Bosch Diesel Injection Distributor Pumps
7.0mm 1/4in.Dr / 15mm Hex
12.6mm 1/4in.Dr / 1/2in. Sq
14.4mm 1/2in.Dr
26.0mm 1/2in.Dr
12.4mm oval socket 1/2in.Dr

Bosch VE Pump Sockets
t Click picture for more information
14mm Diesel Injector Pipe Wrench

CT4261

Diesel Injector Wrench - 14mm

14mm Open End Ring Wrench
for Diesel Injector Pipes
Ideal for injectors that have difficult access
Twin hexagon profile suitable for most diesel engines
Chrome Molybdenum

14mm Diesel Injector Pipe Wrench
t Click picture for more information
17mm Diesel Injector Pipe Wrench

CT4029

Diesel Injector Wrench - 17mm

17mm Open End Ring Wrench
for Diesel Injector Pipes
Ideal for injectors that have difficult access
Twin hexagon profile suitable for most diesel engines
Chrome Molybdenum

17mm Diesel Injector Pipe Wrench
t Click picture for more information
Flexi-Shaft Carburettor Adjuster

CT1329

Carburettor Adjuster with Flexi-Shaft

Flexi-Shaft Carburettor Adjuster
280mm flexible shaft reaches into confined areas.
5 quick change adapters for multiple applications.
2mm ( 3/32 ) and 2.5mm ( 1/8 ) Hex Bits
4.5 mm and 1/4in. Hex sockets.
and Double D Socket.
Applicable to most GM vehicles and
1.7 to 2.2L Chrysler 1978 onwards

Flexi-Shaft Carburettor Adjuster
t Click picture for more information
Carburretor Synchronize Tool Kit

CT3742

Carburettor Synchronize Tool Kit

Vacuum Carburettor Synchronizer Kit
To synchronise the values of up to 4 carburettors
Features a bank of 4 gauges with lockable valves
80mm gauges with fixed plate and 4 x 750mm rubber hoses.
Long and short carburettor adaptors and connectors.

Carburretor Synchronize Tool Kit
t Click picture for more information
False Actuator Kit

CT3689

False Actuator Kit

False Actuator Kit
for Delphi Sealed Rail Kits to extend
testing on common rail diesel engines.
The false actuators trick the common rail pump
into producing the maximum pump pressure which
confirms the pump is able to work under maximum load.
For Bosch | Delphi | Denso | Siemens

False Actuator Kit
t Click picture for more information
Flow Meter and Adaptor Set

CT2236

Flow Meter and Adaptor Set

Flow Meter and Adaptor Set for Common Rail Diesels
Measurers the amount of fuel injectors return to the deposit tank.
For use on up to 6 Injectors.
Adaptors for Bosch / Siemens / Denso / Delphi injectors

Flow Meter and Adaptor Set
t Click picture for more information
Flow Meter Adaptor Set

CT3682

Flow Meter Adaptor Set - 24pc

24pc Flow Meter Adaptor Set
For common rail diesel engines.
To be used on injector nozzles together with common rail diagnosis kit.
Adaptors fit most systems such as Siemens . Bosch . Denso etc.

Flow Meter Adaptor Set
t Click picture for more information
Diesel Injector Flow Meter

CT3756

Diesel Injector Flow Meter

Flow Meter for Common Rail Diesel Engines
Measures the return flow of diesel injectors.
Allows simultaneous measurement of the pressure
in 6 injectors and identifies any damaged injectors.
For Bosch | Delphi | Denso | Siemans systems.
Graduated reservoir bottles : 105ml capacity
Fuel-resistant transparent hoses : 650mm long.
Graduated manometer tubes : 95ml capacity
With bottle rack hanger for engine bay.

Diesel Injector Flow Meter
t Click picture for more information
Fuel Injection Pressure Test Kit

CT3376

Fuel Injection Pressure Test Kit

Fuel Injection Pressure Test Kit
For Schroder test-port fuel injection systems.
Quick coupling system with safety valve.
Dual scale gauge - 0-145psi and 0-1000kpa
with hanging hook and protective bumper.

Fuel Injection Pressure Test Kit
t Click picture for more information
Turbo Pressure Gauge - 3 Bar

CT4441

Turbo Pressure Gauge - 3 Bar

Turbo Pressure Gauge
Fuel Injection Pressure Gauge
Suitable for all vehicles.
Supplied with nut and 2M PU tube.
Pressure: 1 to 3 Bar

Turbo Pressure Gauge - 3 Bar
t Click picture for more information
Fuel Injection Test Set

CT2235

Fuel Injection Test Set

41pc Fuel Injection Test Set
High Pressure Gauge with Dual Readings of 0-145psi and 0-1000kpa
Low Pressure Gauge with 0-15psi or 0-100kpa
Adaptors Feature Quick Couplings for Easy Connection

Fuel Injection Test Set
t Click picture for more information
Diesel Injector Nozzle Tester

CT0590

Diesel Injector Nozzle Tester

Diesel Injector Nozzle Tester
Used to adjust and calibrate the injection nozzle opening pressure
and to carry out leakage / spray pattern and chatter characteristic tests.
For nozzle sizes - R | S | T
With 100mm Pressure Gauge : 0-60 Mpa / 0-600 bar
and supplied with 1 - M12 pipe and 2 - M14 pipes.

Diesel Injector Nozzle Tester
t Click picture for more information
Fuel Injector Tester

CT3422

Fuel Injector Tester - 12V

Fuel Injector Tester
For Injector fuel delivery problems on
petrol vehicles with electronic fuel injection.
Powered by the 12 Volt vehicle battery.
Large LED display / 4 Pulse Modes
Detects faults such as clogged or leaking fuel injectors
sluggish or sticky fuel injectors and wiring harness faults.

Fuel Injector Tester
t Click picture for more information
Noid Light Set

CT1951

Noid Light Set - 11pc

11Pc Electronic Fuel Injection Test Light Set
Crucial for electronic fuel injection systems
Systems covered :
TBI - Ford |GM | Geo
PFI - Bosch|GM
SCPI - GM / Multec 2 / 1987
GM 1982 equipped vehicles.

Noid Light Set
t Click picture for more information
14mm Injector Line Socket

CT4498

Injector Line Socket - 14mm 3/8in.Dr

Injection Line Flare Nut Socket
14mm - 3/8in.Dr
For Mercedes Benz Sprinter
Can be used on any 14mm flare nut
Maximum Torque : 25Nm
Chrome-Molybdenum

14mm Injector Line Socket
t Click picture for more information
17mm Injector Line Socket

CT3955

Injector Line Socket - 17mm 3/8in.Dr

17mm Fuel Injection Line Socket - 3/8in.Dr
120mm Long Open 12 point socket for screwed in Injection Lines
found on Diesel Common Rail Injection Systems
For BMW and Opel 2.5TD Diesel Engines

17mm Injector Line Socket
t Click picture for more information
14mm Injector Line Socket

CT3956

Injector Line Socket - 14mm 1/2in.Dr

14mm Fuel Injection Line Socket - 1/2in.Dr
120mm long Open 12 point socket for screwed in Injection Lines
found on Diesel Common Rail Injection Systems
For BMW and VW Diesel Engines.

14mm Injector Line Socket
t Click picture for more information
17mm Injector Line Socket

CT3957

Injector Line Socket - 17mm 1/2in.Dr

17mm Fuel Injection Line Socket - 1/2in.Dr
120mm long Open 12 point socket for screwed in Injection Lines
found on Diesel Common Rail Injection Systems
For Mercedes vehicles

17mm Injector Line Socket
t Click picture for more information
19mm Injector Line Socket

CT3958

Injector Line Socket - 19mm 1/2in.Dr

19mm Fuel Injection Line Socket - 1/2in.Dr
125mm long Open 12 point socket for screwed in Injection Lines
found on Diesel Common Rail Injection Systems
For Mercedes vehicles

19mm Injector Line Socket
t Click picture for more information
Injector Line Socket Set

CT4637

Injector Line Socket Set - 3pc

3pc Injection Line Socket Set
1/2in.Dr / 12 Point / 125mm Deep
For the removal and re-connection of Diesel Fuel Injector Line fittings.
14mm for BMW | VW vehicles.
17 and 19mm for Mercedes vehicles.

Injector Line Socket Set
t Click picture for more information
Injector Line Socket Set

CT3954

Injector Line Socket Set - 6pc

6pc Diesel Injector Line Socket Set - 1/2in.Dr
Sizes - 12 | 14 | 16 | 17 | 18 | 19mm x 100mm Deep
For dismantling injectors on most diesel engines.

Injector Line Socket Set
t Click picture for more information
Ford Duratorq Injector Socket

CT4511

Diesel Injector Socket - 21mm

21mm Ford Duratorq Diesel Injector Socket
1/2in.Dr with Cut Away
For use on the Ford Duratorq Diesel Engine
OEM 303-677

Ford Duratorq Injector Socket
t Click picture for more information
Ford Duratorq Injector Alignment Tool

CT3735

Injector Alignment Tool - Ford

Ford Duratorq Diesel Injector Alignment Tool
For Ford Duratorq Diesel Engines
2.0 / 2.2 / 2.4litre DI / TDCI / TDDI fitted to -
Mondeo 2000 - 2007
Transit 2000 - 2006
Jaguar X type 400

Ford Duratorq Injector Alignment Tool
t Click picture for more information
Diesel HGV Injector Socket

CT3447

Fuel Injector Socket - Diesel HGV

HGV Diesel Fuel Injector Nozzle Socket
For the removal of diesel injector nozzles on
MAN / Mercedes and Sania commercial vehicles
Use with a 22mm Spanner

Diesel HGV Injector Socket
t Click picture for more information
Diesel HGV Injector Socket

CT4402

Fuel Injector Socket - Diesel HGV

Diesel Injection Valve Socket
For MAN and Mercedes Trucks
4 Tooth Socket x 72mm Deep
22mm - inside diameter
28mm - outside diameter
Applicable to : MAN 422 / 403
Mercedes Benz and Scania Trucks.

Diesel HGV Injector Socket
t Click picture for more information
Fuel Injector Top Cap Socket Set

CT4629

Fuel Injector Socket Set - 4pc

4pc Injector Socket Set 1/2in.Dr
Sizes: 25 | 27 | 29 | 30mm
For removing the top cap and connectors on diesel fuel injectors.
Deep sockets with wide cut-out for the most popular injectors in modern vehicles
Chrome Vanadium

Fuel Injector Top Cap Socket Set
t Click picture for more information
Diesel Injector Socket Set

CT0358

Fuel Injector Socket Set - 4pc

4pc Diesel Truck Injector Socket Set
70mm 4 Teeth with M14 x 1.5mm receiver thread
72mm 4 Teeth
120mm 4 Teeth
120mm 3 Teeth for injectors with electrodes

Diesel Injector Socket Set
t Click picture for more information
Diesel Injector Socket Set

CT3762

Fuel Injector Socket Set - 4pc

4pc Diesel Truck Injector Socket Set
for working on nozzle holders
1/2in. Dr Socket - 72mm long with 4 teeth
2 Sockets with 32mm outer hexagon and 4 teeth
1/2in.Dr Socket - 120mm long with 3 teeth

Diesel Injector Socket Set
t Click picture for more information
Fuel Injector Socket Set

CT3542

Fuel Injector Socket Set - 7pc

1/2in. and 3/4in. Drive
Sizes - 25 / 27 / 28 / 29 / 30mm
Suitable for most Injectors with Bosch and Siemans nozzles
Suitable for Citroen / Peugeot vehicles

Fuel Injector Socket Set
t Click picture for more information
Fuel Injector / Glow Plug Socket Set - 9pc

CT4482

Fuel Injector / Glow Plug Socket Set - 9pc

9pc Diesel Injector and Glow Plug Socket Set
1/2in.Dr Diesel Injector Sockets :
21mm x 90mm |
22mm x 78mm | 22mm x 110mm
27mm x 78mm |
28mm x 78mm | 28mm x 83mm
3/8in.Dr Glow Plug Sockets :
8 | 10 | 12mm x 158mm long with Universal Joint.

Fuel Injector / Glow Plug Socket Set - 9pc
t Click picture for more information
Diesel Injector Removal Set

CT4486

Fuel Injector Removal Set - 6pc

6pc Diesel Injector Removal Set
Adaptor sizes :
M20 x 1.5 inner thread to M14 x 1.0 inner thread
M20 x 1.5 inner thread to M17 x 1.0 outer thread
M20 x 1.5 inner thread to M20 x 1.0 outer thread
M20 x 1.5 inner thread to M25 x 1.0 outer thread
M20 x 1.5 inner thread to M27 x 1.0 outer thread
10mm Tamperproof Hex Bit / 1/2in.Dr Socket
For removing Bosch / Denso / Siemens and Delphi injectors.

Diesel Injector Removal Set
t Click picture for more information
Fuel Injector Extractor Set

CT3528

Fuel Injector Extractor Set - 3pc

3pc Fuel Injector Extractor Set
Suitable for Mercedes CDI engines
Impact Extractor - 1.85kg / 470mm
Injector Claw
Injector Adaptor

Fuel Injector Extractor Set
t Click picture for more information
Injector Extractor Set

CT3189

Injector Extractor Set - 9pc

9pc Mercedes Injector Extractor Set
For removing seized injectors without dismounting the cylinder head.
Slide Hammer - 1.75kg
Adaptor - M17 x 1.0
Adaptor - M27 x 1.0 for bosch injector nozzle
Adaptor / Puller W/M12 x 1.75P

Injector Extractor Set
t Click picture for more information
Injection Puller Set

CT3154

Injection Puller Set - 14pc

14pc Injection Puller Set
For the reliable removal of Bosch / Delphi / Deso and Siemans diesel Injectors
1/2in.Dr Injector Sockets - 25 / 27 / 29 / 30mm
7 Injector Adaptors and Slide Hammer

Injection Puller Set
t Click picture for more information
VAG Fuel Injector Service Kit

CT3506

Fuel Injector Service Kit - VAG

18 piece Kit for the removal and installation of petrol injectors on VAG vehicles.
Applicable to 1.4 / 1.6 / 1.8 / 2.0 / 2.7V6 / 3.2V6 / 3.6V6 and 4.2V8 FSI engines.

VAG Fuel Injector Service Kit
t Click picture for more information
Diesel Injector Extractor Set

CT0536

Diesel Injector Master Kit

Diesel Injector Master Kit
Suitable for the removal of Bosch / Delphi /
Denso / Siemens and Pumpe Duse diesel injectors.
1.3kg Slide Hammer with 150mm Shaft.
4kg Slide Hammer with 400mm Shaft and Handle.
With various Male and Female Adaptors.
Pump Duse Injectors Adaptors.
Injector Sockets - 25 | 27 | 29 | 30mm

Diesel Injector Extractor Set
t Click picture for more information
Fuel Injector Master Service Kit

CT3507

Fuel Injector Master Service Kit

Diesel Injector Extractor Set
With adaptors and Slide Hammers -
1.6kg | 2.7kg | 5.1kg
Pulling Claws with fork opening.
5 slotted 6 point 1/2in.Dr sockets -
25 | 27 | 28 | 29 | 30mm x 100mm
Injector extractor sleeve with shells.
M27 Pulling adaptors.

Fuel Injector Master Service Kit
t Click picture for more information
BMW Fuel Injector Service Kit

CT3617

Fuel Injector Service Kit - BMW

BMW Fuel Injector Service Kit
Bosch and Common Rail injectors
mounted on many BMW vehicles.
No need to dismantling the cylinder head.
Blower adaptor to clean the injector seats.
M16 - M17 forcing screw | support feet
Hex wrench to remove solenoids
29mm injector socket with 1/2in. Dr

BMW Fuel Injector Service Kit
t Click picture for more information
BMW Fuel Injector Remover

CT4054

Fuel Injector Remover - BMW

Fuel Injector Service Tool
For the removal and installation of high pressure injectors
with hold down top found in the BMW N20 and N55 series engine.
Coated steel and anodised aluminium
BMW OEM REF : 130320

BMW Fuel Injector Remover
t Click picture for more information
BMW Fuel Injector Pump Service Tool

CT4849

Fuel Injector Pump Service Tool - BMW

BMW Injection Pump Wheel Assembly Tool
For Holding the sprocket during assembly of the injection pump.
Suitable for BMW engines : M47 | M47T2 | M47TU | M57 | M57TU

BMW Fuel Injector Pump Service Tool
t Click picture for more information
Diesel Injector Puller

CT3583

Fuel Injector Puller - Diesel

Diesel Injector Puller
For Citroen / Peugeot 2.0 / 2.2HD1 injectors.
With Pulling Bridge and 3 Bridge Legs
Injector Sockets : 25mm | 29mm Diameter
Injector Force Screw Threads :
17mm Male x 1mm Pitch
25mm x 1mm Pitch
Security Hex Key : 10mm

Diesel Injector Puller
t Click picture for more information
Fuel Injector Puller - Diesel

CT3413

Fuel Injector Puller - Diesel

Diesel Fuel Injector Puller
For the removal of stubborn diesel injectors
For C-Class Mercedes CDI engines

Fuel Injector Puller - Diesel
t Click picture for more information
Diesel Injector Puller

CT2101

Diesel Injector Puller

Diesel Injector Puller with Adaptor
Aids Removal of Bosch and Lucas Diesel Injectors
M8. M12. M14 Adaptors

Diesel Injector Puller
t Click picture for more information
Mercedes Diesel Injector Puller

CT4071

Injector Puller Set - 6pc Mercedes

6pc Injector Puller Set
for Mercedes CDI engines
For removing common rail injectors
without having to disassemble cylinder head.
Applicable to Mercedes-Benz
CDI engines 611 | 612 | 613 etc.
Injection puller with impact hammer.

Mercedes Diesel Injector Puller
t Click picture for more information



Next Last

Product Search

Search Icon
Section 1 Icon Section 2 Icon Section 3 Icon Section 4 Icon Section 5 Icon Section 6 Icon Section 7 Icon Section 8 Icon Section 9 Icon Section 10 Icon

© Cannon Tools Limited  -  2017 All Rights Reserved   •  20 Station Road,  Rowley Regis,  West Midlands,  B65 0JU,  United Kingdom  |  T +44 (0) 121 561 6760
