T100 Star Bit - Tamperproof
For Mercedes Camshaft Pulley
1/2in.Dr x 78mm Long
For correcting the position on camshaft pulley
Applicable : M133 / M157 / M270 / M271 / M276 / M278
Chrome-Molybdenum
Also found in CT4426

Mercedes Auxilliary Belt Tensioner Tool
For tensioning and loosening the damper spring without damage.
on Mercedes-Benz W169 | W245 Engines
with air conditioning and / or stop-start function :
Suitable for following vehicles :
A-Class W169 / 2004 - 2012
A150 | A160 | A170 | A180 | A200 | A200T
B-Class W245 / 2005 - 2011
B150 | B160 | B170 | B180 | B200 | B200T
OEM Code : 266589003100

Mercedes V-Belt Tensioning Tool
For setting the tension wheel and fitting the ribbed belt.
Suitable for Mercedes models : 168 | 169 A-Class | 245 B-Class
Length : 620 mm
Size : 15mm

Mercedes Crankshaft Oil Seal Installation Kit
Used to install the front and rear crankshaft oil seal.
Applicable to:
M102 | 111 | 112 | 113 | 137 | 156 | 159 | 272 | 275 |
285 | 601 | 602 | 603 | 604 | 605 | 606 | 628 | 629.
OEM Code :119589011400 | 11589084300

Mercedes Crankshaft Oil Seal Installation Kit
Specifically designed to install crankshaft front and rear seals
on Mercedes M651 diesel engines .
OEM Code : 651589006100 | 651589016100

Chrysler Timing Tool Set
For Chrysler / Jeep / Mercedes
For timing Chrysler CRD diesel engines
and a huge range of Mercedes-Benz diesel chain drive engines.
with flywheel locking plates with M6 x 90mm bolts
and camshaft locking pin set.

Mercedes Timing Tool Set
For Locking Camshafts on Chain Drive 1.6 / 2.0 Petrol Engines.
Supplied with small and large diameter Clamp pieces
to ensure the camshaft is correctly held in place.
Includes T100 TP Star Bit for Camshaft Pulley.
For the removal and assembly of the camshafts.
Applicable to : Mercedes-Benz M133 / M270 / M274
found late A / B Class CLA | C and E Class vehicles.

Mercedes Timing Chain Guide Rail Pins Remover
for Mercedes-Benz 1.6L / 2.0L Petrol Engines from 2011.
Designed to extract the timing chain slipper guide.
Allows the removal of the pins with the minimum of disassembly.
Applicable to : A / B / C / E Class and GLA.

Mercedes Flywheel Locking Tool
for Mercedes-Benz - A / B Class and CLA / GLA
Designed to fit in place of the starter motor to lock the crankshaft
via the flywheel ring gear on the Mercedes-Benz engines.
Applicable to :
A class / 2013 - 2019 | B class / 2012 - 2019
CLA / 2013 - 2019 | GLA / 2014 - 2020

Mercedes Flywheel Retaining Tool
for Mercedes-Benz 1.8 | 2.1 M651 Diesel Engines.
Bolts in place of the starter motor to lock the flywheel
to prevent it turning when removing the crankshaft front pulley fixings
Applicable to : A / B / C / CLA / E / GLA / GLK / V Class - 2008
Also light commercials vehicles - Sprinter / Viano and Vito
OEM Code : 651589024000

Flywheel Locking Tool
for Mercedes / Renault / Dacia - 0.9L | 1.3L | 1.6L Petrol Engines
For locking the flywheel to allow easy removal
of the crankshaft pulley and flywheel bolts.
Applicable to : Mercedes-Benz A / B class / CLA / GLA / GLB.
Renault Arkan / Clio V / Captur / Kadar / Megane and Talisman.
Dacia Dokker / Duster and Lodgy

Timing Tool Set - Mercedes M282
For timing chain replacement and setting the timing on
Mercedes 1.3M 242.914 and Renault 1.3 LH5H -
chain driven twin camshaft 4 cylinder 1.3 Petrol Engines
OEM Code : 282589002300

Mercedes Timing Tool Set
Camshaft Locking Tools
for Mercedes-Benz - 1.8 | 2.1 CDi M651 Diesel Engines.
Applicable to :
A | C | E | M | S Class | CLA and GLK
Sprinter / SLK / Viano and Vito
OEM Codes : 651589004000 | 651589094000

Mercedes Timing Too Set
Mercedes-Benz Camshaft Valve Timing Kit
for 1.8 | 2.1 | 2.2 M651 Diesel Engines.
The kit enables the engine to be locked in its timed position
for the removal and refitting of the camshaft drive chain.
The kit includes the balance shaft alignment tool.

OEM Codes :
651589004000 | 651589014000 | 651589026300

Mercedes Timing Tool Set
Timing Chain Mounting Tool Set
for Mercedes-Benz M651 Diesel Engines
Allows precise positioning by preventing the timing chain skipping
and the camshaft sprockets moving when replacing the timing chain
without removing the camshaft sprockets.
Camshaft - Adjusting Tool and Special Wrench
Crankshaft Turning Tool
Sprocket Feet Shaft plus Screws
Timing Chain Guide Tool plus Screws

Mercedes Timing Chain Riveting Tool
For renewing and riveting timing chains on Mercedes-Benz Vehicles
Dismantling the timing chain case is often not required
as the new chain can be fed through using the existing chain.
Suitable for models with Duplex and Simplex timing chains with 4mm chain bolt.

Mercedes Timing Tool Set
for Mercedes-Benz M642 CDI Engines
Aligns the camshaft timing angle for correct position.
2 camshaft holding tools with 8 fixing screws
OEM number : 642589003100.

Mercedes Timing Tool Set
for Mercedes-Benz M276 | M157 | M278 Petrol Engines
to correctly align the camshaft timing angle.
OEM Code : 276589014000
See more info for the full list of Mercedes models.

4pc Camshaft Adjuster Set
for Mercedes V6 / V8 - M152 / M157 / M276 / M278 Vehicles
Camshaft Position Sensor Reluctor Setting Tools
Used to mark pulse wheel on removed camshaft.
Can be used in conjunction with CT4076
OEM Code : 278589002300

Mercedes Timing Tool Set
Camshaft Alignment Tool Set
For Mercedes-Benz M271 Petrol Engines
Used for engine timing and belt changing.
Also other camshaft related servicing

Mercedes Timing Tool Set
for Mercedes-Benz / AMG M156 | M159 Engines
For checking and adjusting engine timing.
With Camshaft Holding Tool
Adjusting Plate
Camshaft Adjusting Tool
Camshaft Gear Pre-tensioning Tool
Holds Basic position of camshaft at 40 degrees after TDC.

Mercedes Timing Tool Set
for Mercedes-Benz M112 | 113 V6 and V8 Engines
Allows the camshaft to be aligned and locked into position.
With intake and exhaust cam alignment jigs and the cam holding wrench.
Applicable to M112 | M113 V6 and V8 engines from 1998 onwards.
