Section 5.16

Mercedes Timing Tools

Mercedes Camshaft Pulley Star Bit

CT4512

Star Bit - T100 1/2in.Dr

T100 Star Bit - Tamperproof
For Mercedes Camshaft Pulley
1/2in.Dr x 78mm Long
For correcting the position on camshaft pulley
Applicable : M133 / M157 / M270 / M271 / M276 / M278
Chrome-Molybdenum

Mercedes Camshaft Pulley Star Bit
t Click picture for more information
Mercedes V-Belt Tensioning Tool

CT4635

Ribbed Belt Mounting Lever

Mercedes V-Belt Tensioning Tool
For setting the tension wheel and fitting the ribbed belt.
Suitable for Mercedes models : 168 | 169 A-Class | 245 B-Class
Length : 620 mm
Size : 15mm

Mercedes V-Belt Tensioning Tool
t Click picture for more information
Crankshaft Oil Seal Removal Kit - Mercedes

CT4872

Crankshaft Oil Seal Kit - Mercedes

Mercedes Crankshaft Oil Seal Installation Kit
Used to install the front and rear crankshaft oil seal.
Applicable to:
M102 | 111 | 112 | 113 | 137 | 156 | 159 | 272 | 275 |
285 | 601 | 602 | 603 | 604 | 605 | 606 | 628 | 629.
OEM :119589011400 | 11589084300

Crankshaft Oil Seal Removal Kit - Mercedes
t Click picture for more information
Crankshaft Oil Seal Removal Kit - Mercedes

CT4873

Crankshaft Oil Seal Kit - Mercedes

Mercedes Crankshaft Oil Seal Installation Kit
Specifically designed to install crankshaft front and rear seals
on Mercedes M651 diesel engines .
OEM number : 651589006100 / 651589016100

Crankshaft Oil Seal Removal Kit - Mercedes
t Click picture for more information
Mercedes Petrol Timing Tool Kit

CT4426

Timing Tool Set - Mercedes 1.6 / 2.0

Camshaft Locking Timing Tool Kit
for Mercedes Chain Driven 1.6 / 2.0 Petrol Engines.
Supplied with small and large diameter clamp pieces
to ensure the camshaft is correctly held in place.
Includes T100 TP Star Bit for Mercedes Camshaft Pulley.
For the removal and assembly of the camshafts.
Applicable to : Mercedes-Benz M133 / M270 / M274
found late A / B Class CLA | C and E Class vehicles.

Mercedes Petrol Timing Tool Kit
t Click picture for more information
Flywheel Locking Tool - Mercedes / M651

CT4979

Flywheel Locking Tool - Mercedes / M651

Flywheel Retaining Tool Mercedes Benz M651.
Fits popular 1.8 and 2.1 diesel engines.
Bolts in place of the starter motor to lock the flywheel
to prevent it turning when removing the crankshaft front pulley fixings
Applicable to : A / B / C / CLA / E / GLA / GLK / V Class - 2008
Also light commercials vehicles - Sprinter / Viano and Vito
Equivalent to OEM 651 589 02 40 00

Flywheel Locking Tool - Mercedes / M651
t Click picture for more information
Timing Tool Set - Mercedes / M651

CT4435

Timing Tool Set - Mercedes / M651

Mercedes Timing Tool Set
Camshaft Locking Tools
for Mercedes M651 - 1.8 / 2.1 CDi diesel engines.
Applicable to : A | C | E | M | S Class | CLA and GLK
Sprinter / SLK / Viano and Vito

Timing Tool Set - Mercedes / M651
t Click picture for more information
Mercedes Timing Chain Riveting Tool

CT4062

Timing Chain Riveting Tool - Mercedes

Mercedes Benz Timing Chain Riveting Tool
For renewing and riveting timing chains.
Dismantling the timing chain case is often not required
as the new chain can be fed through using the existing chain.
Suitable for models with duplex timing chain with 4mm chain bolt.

Mercedes Timing Chain Riveting Tool
t Click picture for more information
Mercedes Timing Tool Kit

CT4076

Timing Tool Set - Mercedes

Engine Timing Tool Kit
for Mercedes M157 | M276 | M278
to correctly align the camshaft timing angle.
See more info for the full list of Mercedes models:

Mercedes Timing Tool Kit
t Click picture for more information
Timing Tool Set - Mercedes

CT3772

Timing Tool Set - Mercedes

Timing Tool Set - Mercedes
Camshaft Alignment Tool Set
for engine timing and belt changing.
Also other camshaft related servicing.
For Mercedes Benz M271

Timing Tool Set - Mercedes
t Click picture for more information
Timing Tool Set - Mercedes / AMG

CT3774

Timing Tool Set - Mercedes / AMG

Mercedes-Benz AMG Timing Tool Set
Basic position of camshaft for a
40 degree crank angle after top dead centre.
Suitable for most Mercedes-Benz AMG vehicles.

Timing Tool Set - Mercedes / AMG
t Click picture for more information
Mercedes Timing Tool Set - M112 / M113

CT4653

Timing Tool Set - Mercedes

Mercedes M112 / 113 Timing Tool Set
For accurately aligning and locking the camshaft into position.
With intake and exhaust cam alignment jigs
and the cam holding wrench.
Mercedes V6 and V8 engines / M112 | M113 - 1998 onwards.

Mercedes Timing Tool Set - M112 / M113
t Click picture for more information
