Section 5.10

BMW Timing Tools

Timing Tool Set - BMW - M3 / S54

CT4600

Timing Tool Set - BMW - M3 / S54

BMW Timing Tool Set
For checking and setting camshaft timing when installing
the VANOS adjustment unit on BMW M3 vehicles with
chain drive 3.2L / 6 cylinder 24 valve S54 petrol engines.
Valve timing checking tool.
Camshaft setting tool and pins.
VANOS alignment lever.
Crankshaft Turning Tool and Locking Pin.
VANOS Spacers.

Timing Tool Set - BMW - M3 / S54
t Click picture for more information
Timing Tool Set - BMW - M40 / M56

CT3579

Timing Tool Set - BMW - M40 / M56

BMW Timing Tool Set
For engine codes M40 to M56 with DOHC engines
For dismantling camshaft for Valve timing and cambelt change.
For a wide range of models

Timing Tool Set - BMW - M40 / M56
t Click picture for more information
Timing Tool Set - BMW - M40 / M70

CT3878

Timing Tool Set - BMW - M40 / M70

BMW Timing Tool Set
Setting and locking set for BMW petrol engines.
Includes tools for setting and locking camshafts.
Plus tools for setting up timing chain tension.
Applicable to BMW -
M40 | M42 | M50 | M60 | M62 | M70

Timing Tool Set - BMW - M40 / M70
t Click picture for more information
Timing Tool Set - BMW - M41 /  M51

CT3427

Timing Tool Set - BMW - M41 / M51

BMW Timing Tool Set
For the Removal and Installation of camshaft chain and adjusting timing on -
BMW Diesel Engines M41 / M51 / M47TU / M47TU T2.
M57TU T2 3.01 1998 - 2008.

Timing Tool Set - BMW - M41 /  M51
t Click picture for more information
Timing Tool Set - BMW - M42 / M60

CT3147

Timing Tool Set - BMW - M42 / M60

Bmw Engine Timing Tool Set
For replacing the timing belt or chain on both petrol and diesel engines.
Special wrench for removing and installing the VANOS unit.
M22 threaded for M42/M60 engines
M26 threaded for M50/M52 engines

Timing Tool Set - BMW - M42 / M60
t Click picture for more information
Timing Tool Set - BMW - M42 / M73

CT4066

Timing Tool Set - BMW - M42 / M73

BMW Single VANOS Camshaft Timing Kit
For setting engine timing during chain removal and installation.
Compatible with some BMW 4 and 6 cylinder none VANOS engines
With Camshaft Locking Plate
VANOS Turning Wrench
and Top Dead Centre Pin

Timing Tool Set - BMW - M42 / M73
t Click picture for more information
Timing Tool Set - BMW - M47

CT3426

Timing Tool Set - BMW - M47

BMW Camshaft Alignment Tool Kit
For BMW M47 2.0 16 valve engine servicing.
Applicable to a wide range of BMW vehicles
With Crankshaft pin / Camshaft setting plate
Clamp for camshaft locking tool and 2 timing pins.

Timing Tool Set - BMW - M47
t Click picture for more information
Timing Tool Set - BMW - M52 / M56

CT3586

Timing Tool Set - BMW - M52 / M56

BMW VANOS Camshaft Alignment Tool Set
Tools to assemble and time the VANOS units on
BMW M52TU / M54 and M56 - 6-cylinder engines.
Alignment Jig Adjusting plate for setting valve timing.
Jig for pre-assembling secondary chain sprockets.
Lock Pin secures chain tensioner during timing.
VANOS Compressed Air Connector

Timing Tool Set - BMW - M52 / M56
t Click picture for more information
Timing Tool Set - BMW - M54 / M62

CT3770

Timing Tool Set - BMW - M54 / M62

BMW M54 / M60 / M62 VANOS Timing Tool Set
with 2 camshaft alignment jigs
Top dead centre pin to align the flywheel
Rigid chain tensioner to tension primary chain.
2 jigs to lock the sensor wheels in place during timing.
Special deep thin wall 32mm socket
Chain Tensioning Bracket Trestle
For VANOS components and adjusting cam timing.

Timing Tool Set - BMW - M54 / M62
t Click picture for more information
Timing Tool Set - BMW / Mini

CT4414

Timing Tool Set - BMW / Mini

Timing Tool Kit - BMW Mini Diesel
Engine timing tool kit for diesel BMW Mini
with engine codes W16D16 / 9HZ and W16D16UO
used on Mini / Clubman 07-10 with chassis R55 | 56 | 57.
Also used on -
Citroen: 1.6 diesels in C2 | C4 | C5 |
Xsara Picasso | Grand Picasso | Berlingo
Peugeot : 1007 | 206 | 307 | 207 | 308 | Partner Mk3

Timing Tool Set - BMW / Mini
t Click picture for more information
Timing Tool Set - BMW / Mini

CT2939

Timing Tool Set - BMW / Mini

BMW Engine Timing Tool Kit
Mini Cooper 2001-06 and Mini Cooper S 2002-06
Camshaft Sprocket Holding Tool
Engine Support Bracket and Tension Assembly Tool
Specifically designed for petrol engines on pre 2009 Mini

Timing Tool Set - BMW / Mini
t Click picture for more information
Timing Tool Set - BMW / Mini

CT4430

Timing Tool Set - BMW / Mini

BMW/ Mini Timing Tool Set - N13 / N18
Comprehensive tool kit for setting camshaft timing on
1.6 petrol engines in BMW and Mini since 2012.
To lock camshafts in 90 degree piston position / TDC.
Camshaft locking fixtures with hold-down bolts
Crankshaft locking pins
Rigid Chain Tensioner

Timing Tool Set - BMW / Mini
t Click picture for more information
Timing Tool Set - BMW / Mini

CT4650

Timing Tool Set - BMW / Mini

BMW Mini Engine Camshaft Timing Tool Set
Variable Camshaft Timing Unit Removal and Installation Kit.
Applicable to : BMW Mini B38 / B48 / B58 Engines.

Timing Tool Set - BMW / Mini
t Click picture for more information
Timing Tool Set - BMW - N20 / N26

CT0537

Timing Tool Set - BMW - N20 / N26

BMW Timing Tool Set
For BMW N20 and N26 Engines
Engine alignment tools applicable to
BMW 4 cylinder turbo engines.
With Camshaft Locking Tool
Camshaft Fixating Base
Alignment Pin
Chain Tensioner

Timing Tool Set - BMW - N20 / N26
t Click picture for more information
Timing Tool Set - BMW - N40 / N45

CT3556

Timing Tool Set - BMW - N40 / N45

BMW Timing Tool Set
For setting and adjusting the timing on BMW 1.6 petrol engines
with Vanos Alignment Plate
Camshaft Setting Plate - Inlet
Camshaft Setting Plate - Exhaust
Timing Chain Tensioner Pre-load tool
Flywheel Locking Pin
Camshaft Setting Plate Securing Screw.

Timing Tool Set - BMW - N40 / N45
t Click picture for more information
Timing Setting Kit - BMW / PSA

CT4436

Timing Setting Kit - BMW / PSA

Petrol Engine Timing Chain Service Tool Kit
for BMW / Mini / PSA vehicles
Essential for the removal or installation of the timing chain assembly
on a range of BMW / Mini and PSA petrol engines.
Kit includes balance shaft aligners
crankshaft gear holding tools
and chain tension locking pin.

Timing Setting Kit - BMW / PSA
t Click picture for more information
Timing Tool Set - BMW - N42 / N46

CT3580

Timing Tool Set - BMW - N42 / N46

BMW Timing Tool Set
For engine codes - N42 . N46 . B18-A . B20-A-B
Tools for dismantling and assembling camshafts.
For models - 1 . 3 . S . X3 . Z4.
Series Type - E87 . 46 . 60 . 85 . 83 . 90 . 91.

Timing Tool Set - BMW - N42 / N46
t Click picture for more information
Timing Tool Set - BMW - N42 / N46

CT3523

Timing Tool Set - BMW - N42 / N46

BMW Timing Setting and Locking Set
For adjusting and setting the timing on BMW petrol engines with the Valvetronic system.
Includes tools to align the Twin Vanos unit.
Suitable for BMW 1.8 and 2.0 Chain Drive engines.

Timing Tool Set - BMW - N42 / N46
t Click picture for more information
Timing Tool Set - BMW - N43

CT3589

Timing Tool Set - BMW - N43

BMW Timing Tool Kit Set
For use on N43 Chain Driven Engines
In Series 1 | 3 and 5 models
Includes Vanos sensor alignment tool

Timing Tool Set - BMW - N43
t Click picture for more information
Timing Tool Set - BMW - N47

CT3190

Timing Tool Set - BMW - N47

BMW Diesel Engine Setting / Locking Tool Set
For timing BMW N47 / N47s 2.0 twin camshaft diesel chain drive engines
Fitted in the 1 Series / 3 Series / 5 Series and X3
Crankshaft turning tool to rotate engine to TDC position

Timing Tool Set - BMW - N47
t Click picture for more information
Timing Tool Set - BMW - N47 / N47S

CT4628

Timing Tool Set - BMW - N47 / N47S

BMW Timing Tool Set
For Diesel N47 / N47S engines with chain drive.
With injection pump lock adapter
Camshaft / Crankshaft and Camshaft Chain Tensioner Lock.

Timing Tool Set - BMW - N47 / N47S
t Click picture for more information
Timing Tool Set - BMW - N51 / N54

CT3588

Timing Tool Set - BMW - N51 / N54

BMW Timing Tool Set
For engine codes : N51 | N52 | N53 | N54
With Camshaft and Crankshaft Locking Tools
Transmitter Wheel Locking Tool.
Suitable for a wide range of models.

Timing Tool Set - BMW - N51 / N54
t Click picture for more information
Timing Tool Set - BMW - N51 / N55

CT4170

Timing Tool Set - BMW - N51 / N55

BMW Timing Tool Set
For the removal and installation of the variable camshaft unit
on BMW 6 cylinder engines : N51 N52 N53 N54 N55
with T.D.C pin
Camshaft Alignment Jig
Tensioner Adjuster
Setting Gauge

Timing Tool Set - BMW - N51 / N55
t Click picture for more information
Timing Tool Set - BMW - N62 / N73

CT3773

Timing Tool Set - BMW - N62 / N73

BMW Timing Tool Set
BMW Engine Camshaft Alignment Tool Kit
To enable the correct timing when servicing
N62 / N73 engines on dual camshafts.
Gauges for locating camshaft in TDC position
Pin for locking flywheel in TDC position

Timing Tool Set - BMW - N62 / N73
t Click picture for more information
Timing Tool Set - BMW - N63 / N74

CT3882

Timing Tool Set - BMW - N63 / N74

BMW Timing Tool Set
For VANOS timing on N63 and N74 engines.
Camshaft Alignment Fixtures
Two Camshaft Alignment Jigs
Crankshaft TDC Pin
VANOS Timing Tools

Timing Tool Set - BMW - N63 / N74
t Click picture for more information
