5pc Star Bit Set - 3/8in.Dr
Universal Joint Socket
Sizes : T30 | T40 | T45 | T50
T45 Used for Timing Belts on VAG Petrol and Diesel Engines

VAG Diesel Pump Sprocket Puller
15mm Hex Drive with 24mm Hex Retainer.
For removing the high pressure fuel pump on 1.4 | 1.6 | 2.0L TDi engines.
Applicable to VW and SEAT vehicles from 2008 - 2013.
OEM Code : T10489.

VAG Pump Pulley Remover
For the removal of the high pressure pump hub
on 1.6L and 2.0L TDi common rail diesel engines.
OEM Code : T40064

VAG Camshaft Adapter Socket
3/8in. Drive / S45C Steel.
Use to rotate and hold the intake camshaft during timing chain service
on 4 cylinder 1.8L and 2.0L TFSi generation III direct injection engines.

Audi / VW Crankshaft Pulley Holding Tool
For holding the crankshaft pulley when removing or installing the crankshaft central bolt.
AUDI : A3 | A6 | Q5 2004 onwards
VW : TSI / TFSI engines with chain 1.8T | 2.0L 4V
OEM Code : T10355

VAG Service Position Front End Support Guide Set
Suitable for extending the front panel of the vehicle
to provide increased space in engine compartment
for carrying out various service applications.
Guides : M8 x 1.25mm / M10 x 1.5mm
Applicable to :
Audi : A4 / A5 / A6 / A8 /Q5
Skoda : Superb
VW : Passat

VAG Camshaft Adjuster Sockets - 3/8in.Dr
For the camshaft adjustment of 4/3-way central valve.
Fitted to : Audi A3 | A4 | A5 | Q5 1.8
and VW 2.0 litre engines with chain drive

VAG Camshaft Sprocket Locking Tool
VAG 1.0L TSI 3 cylinder petrol engines
For locking the camshaft in position during engine timing and servicing.

OEM Code : T10476
Common to : CT4424 | CT4622 | CT4651

VAG Timing Tool Set
For Jetta / Santana / Gran Lavida / Golf 7
Locks camshaft when checking and adjusting timing
1.0 MPI and 1.0 MPI / GNC Petrol Engines
With Crankshaft Locking Bolt
Camshaft Adjusting plate
Camshaft Sprocket Locking Tool
Tension Adjusting Wrench
Assembly Tool

VAG Camshaft Spacer Set
2 sizes of spacers for locating
the AVS spline ends on the camshaft.
For Audi A4 2008 | Q5 2009
4 cylinder petrol injection 2.0L turbo engine
OEM Code : T40191

VAG Camshaft Locking Tool
Applicable to -
VW | AUDI 1.4 / 1.6L
VW Lupo | Polo | Golf IV | Bora / Audi A2 vehicles
OEM Codes : T10016 | T10074

VAG Adjustable Camshaft Locking Tool
for VW 12 - 30 Valve vehicles.
For precise assembly of the auxiliary belt
avoiding distortion of the camshaft.
Adjustable camshaft locking strap will hold the twin cams in place.
OEM Codes : 3391 | 3242 | 3243

VAG V6 Camshaft Alignment Tool
Applicable to 1995-2004
new body style VW and AUDI models.
OEM Code : VAG 3391

VAG V6 Camshaft Alignment Tool
Essential tool for locking and setting the camshaft
and crankshaft during timing belt replacement.
With Mounting Bracket for difficult access.
Applicable to :
Audi : 80 | A4 | Coupe | Cabriolet | A6 | A8
VW V6 engine codes : ABC | AAN

VAG V8 Camshaft Alignment Tool
Designed to align the camshafts at TDC position
when adjusting and assembling.
Applicable to VAG V8 5-valve engines.
OEM Code : T40005

VAG Camshaft Alignment Set
Specially designed to set the Camshaft in the correct position for servicing.
Audi - A4 / A6 / A8 / A11 ( 97 - 04 )
VW - Passat ( 98 - 04 )

VAG Camshaft Drive Belt Sprocket Puller
For removing the camshaft sprockets
on a variety of VW and Audi camshafts.
Includes 17mm and 23mm pulling arms.
OEM Code : T40001

VAG Camshaft Holding / Alignment Tool Kit
for Audi A4 | A6 | A8 - V6 3.0 Petrol Engines
With Camshaft Locking Tool
Crankshaft Retainer Tool
Tensioner Pulley Wrench
Used for timing belt replacement and engine repair.

Engine codes : ASN | AVK | BBJ

OEM Codes : 3387 | T40011 | T40026 | T40028 | T40030

VAG Crankshaft Locking Pin - M14 x 1.5
for locking the crankshaft in TDC position
while Replacing the timing belt on
Audi A6 2005 models with 6 cylinder 2.4 / 3.2 FSI engines
OEM Code : T40069

VAG Crankshaft Turning Adaptor
22mm Square with 12mm Rotating Pivot Pin
Dual Drive : 1/2in.Dr plus 24mm Hex
Used for turning the crankshaft pulley.
Applicable to : 2.4 | 3.2 | 4.2 FSI Engines.
OEM Code : T40058

VAG Crankshaft Locking Tool Set
Suitable for VW Touareg 2003 >
Phaeton 2003 > with 10 cylinder Diesel Engines.
For locking crankshaft when adjusting engine timing.
Adjusting bolts for mounting the engine control module

OEM Codes : T10195 | T10200

VAG Crankshaft Seal Flange Remover and Installer
for 1.4 and 1.6 - 16 Valve VAG engines
fitted to Audi / Skoda / Fiat and VW vehicles
Specific tool vital to ensure the correct alignment
of the main seal house crankshaft sensor.
The Seal housing carries the crankshaft sensor mounting.
OEM Code : T10017

VAG Crankshaft Seal Flange Installation Tool
Designed to renew the crankshaft oil seal on Audi / VW vehicles
Applicable to 16V / 20V - 1.9 / 2.0 Diesel Engines since 2006.
For 4 Valve Diesel engines with integrated sender wheel.
Audi A3 4-cyl. VW Golf / Touran
OEM Code : T10134

VAG Crankshaft Oil Seal Tool
Designed for VW 2.5 TDI | 2.5 Blue TDI Engines.
The flywheel end oil seal is integral with the oil seal housing
and speed sender and is supplied with a new timing ring.
If the oil seal is faulty then the whole assembly must be renewed.
Suitable for VW Crafter 2.5L / 2006 - 2013
Engine Codes : BJJ | BJK | BJL | BJM | CEBA | CEBB | CECA | CECB
OEM Code : T50010

VAG Tensioner Wrench
Multi-position timing belt tension wrench for
Volkswagen | Audi | Skoda | Seat vehicles.
5 variable positions for extra easy use.
Suitable for both petrol and diesel engines.

VAG Timing Tool Set
For Audi / Seat / Skoda / VW
1.9 / 2.0 TDI pump / nozzle
1.9 TDI / conventional
2.5 V6 TDI | 3.3 V8 TDI Diesel Engines
1.2 3-cylinder and 1.4 | 1.6 Petrol Engines
With Camshaft Locking Tools
Injection Locking Tools
Crankshaft Locking Tools
and Injection Nozzle Wrench : 22mm.

VAG Timing Tool Set
For 2.0 FSI Petrol Engines since 2003.
Found on - Audi A3 | VW Golf and Touran models
Includes :
Pin Wrench
Alignment Pin
Locking Pins
Chain Tensioner / Tensioning Screw
Camshaft Locking Tool

VAG Camshaft Locking Tool
W8 and W12
For aligning the camshafts on
W8 - V6 R32 3.2L
and W12 6.0L
OEM Codes : T10068 | T10068A

VAG Crankshaft Rotation Tool
for VAG 5 Cylinder Engines
Necessary for crankshaft adjustment and as use as a lever.
Suitable for all 5 cylinder VW diesel engines -
VW touareg as of 2003 and transporter as of 2004
Fixing screw allows easy mounting on crankshaft.
OEM Code : T10225

VAG Water Pump Removal Kit
This kit is essential for the removal of the water pump
and the alignment of the engine at top dead centre
on Transporter and Touareg vehicles
For 2.5L 5-cylinder TDI engines.

VAG Timing Tool Set
For 2.5 / 4.9D / TDI PD Touareg and Phaeton Models
Suitable for VW T5 as of 2004
Touareg and Phaeton as of 2003 with 5 and 10 cylinder engines.
Engine Codes : AXD | AXE | BAC | BLJ | BLK | BNZ | BPC | BPD | BPE
Camshaft Locking Tools and Clamp for 5 and 10 cylinder engines.
Special Socket for rotating the crankshaft of 5 cylinder engines.
Crankshaft Locking Wrench for 5 cylinder engines.
Tensioner Wrench.

VAG Timing Tool Set
For checking and setting camshaft timing on
Audi V6 | V8 and VI0 Engines with Chain Drive
Camshaft Locking Tool
Crankshaft Turning Adaptor
Crankshaft Locking Pin
Chain Tensioning Locking Pin

VAG Timing Tool Set
For locking the camshaft when adjusting timing
on Audi / Bentley / VW vehicles.
Applicable to : 8 cylinder 4.0 TFSI engines
A6 - 2011 | A8 - 2010
OEM Code : T40264

VAG Diesel Engine Setting / Locking Kit
Cranshaft Locking Tool.
Camshaft / Tensioner Locking Pins.
For Engines with Hydraulic Belt Tensioners in -
VAG : 1.2D | 1.4D | 1.9D | 2.0TDi PD Belt Drive Engines.
Suitable for Audi / Seat / Skoda / VW and some Ford vehicles.
OEM Codes : 3359 | MP1-301 | T10008 | T10050 | T20102

VAG Timing Tools
For Audi / VW 2.5 V6 TDi Engines
with Crankshaft Locking Pin
and Camshaft Locking Plates.
VW Passat 2.5 V6 TDI
Audi A4 / A6 / A8 2.5 V6 TDI
Skoda Superb 2.5 V6 TDI

VAG Crankshaft Locking Tools
for 1.4 | 1.6 |1.9 | 2.0 TDI Engines / 2002 - 2008
Allows checking and adjustment of the engine timing
during tooth belt and camshaft replacement.
Crankshaft Locking Tool
Pump Wheel / Camshaft Locking Tool
Crankshaft Locking Tool
Locking Pin - 4mm
Locking Pin for V-belts

VAG 1.9 TDi Timing Tool
Applicable to
Seat : Cordoba / Ibiza / Inca / Leon / Toledo - 99 - 06
Volkswagen : Bora / Golf / New Beetle
OEM Codes : T20038 | T10098

VAG Timing Tools
for VW 1.2L Engines 8155-1
Also replacement parts for CT3146 Timing Set
OEM Code : T10123

VAG Timing Tool Set
Setting and Locking Kit
Tools for locking top dead centre and
setting tools to re-check correct alignment
on Petrol and Diesel Engine Vehicles
Applicable to : PSA / VAG and Volvo.

VAG Timing Tool Set
Diesel Engine Timing Belt replacement
Camshaft and Crankshaft Locking Tools
Camshaft Wheel Puller | Balance Shaft Fixing Tool
Suitable for a wide range of VW Group vehicles.

VAG Timing Tool Set
For 1.6 | 2.0 TDi CR Diesel Engines from 2012 onwards.
Cambelt Tensioner Locking Tool 2.5 mm
Hex Keys : 6mm | 8mm
2 Fuel Pump Locking and Camshaft Alignment Pins
Auxiliary Drive Tensioner Pin
Camshaft / Crankshaft Timing Pin
Crankshaft Timing Tool and Locking Pin
Sprocket Holding Tool for High Pressure Fuel Pump.

VAG Timing Tool Set
Diesel Engine Setting / Locking Kit
for Belt Drive 2.4 / 2.5D SDI / TDI / TDICR engines.
Crankshaft Pulley Holding Tool
Camshaft Setting Plate
Injection Pump Locking Pin
Crankshaft Locking Pin
Tensioner Adjuster
VW Crofter / IT and Transporter

VAG Timing Tool Set
For use on Audi / VW 3.0 TDi diesel engines.
Applicable to :
Audi A4 | A5 | A6 | A7 | A8 | Q5 | Q7 - 2014 onwards
VW Amorak - 2014 onwards.

VAG Timing Tool Set
For Timing Belt replacement
on 2.7 / 3.0 V6 TDi PD
Common Rail Diesel Engines
With Camshaft Wheel Puller
Camshaft and Crankshaft Locking Tools
Suitable for a wide range of Audi / VW vehicles

VAG Timing Tool Set
for 2.7 | 3.0 | 4.0 | 4.2 Diesel Engines
Crankshaft Adjusters - Gearbox End / Pulley End
Cam & Crankshaft Locking / Retaining Pins
Camshaft Sprocket Adjuster
HP Pump Sprocket Remover
Balance Shaft Locking Pin

VAG Timing Tool Set
for 1.2 / 1.4 / 1.9 / 2.0 / 2.7 / 3.0 Diesel Engines
also 1.9 TDI PD Engines
Allows the adjustment of phase timing
and cylinder head assembly / installation.
Camshaft Alignment / Locking Pins and Tools
Crankshaft Adapters / Locking Pins / Tools
Injection Pump Locking Pins
Tensioner / Pulley Locking Pins

VAG Timing Tool Set
for VW Lupo / Polo etc.
For 1.2 Litre 3 Cylinder Engines from 2002 Onwards.
For Volkswagen | Seat | Skoda vehicles
OEM Codes : T10123 | T10121 | T10120

VAG Timing Tool Set
Tensioner Adjuster Set
for VAG Timing Belts
Set contains three specialised wrenches and pins
required to access the timing belt tensioners
fitted to a wide range of VAG petrol and diesel engines.

VAG 3.6 FSi Injection Pump Sprocket Retaining Tool
VAG 3.6L FSi Injection Pump Sprocket Retaining Tool
For holding the high pressure pump in place when adjusting valve timing.
Suitable for VAG 3.6L / 6 cylinder / 4 valve engines.
VW Passat - 357 / 3C2 / 3C5 starting from 2006
VW Touareg - 7L6 / 7LA starting from 2006
Audi Q7 - 4LB starting from 2007

VAG Timing Chain Clamping Tool
for 4.2 V8 FSi Engines
Required for tensioning the timing chain
when working on the camshaft adjuster and other engine repairs.
For 4.2 litre FSi engines with 8 cylinders and direct injection.

VAG Timing Tool Set
Audi A4 / A6 / A8 / Q5 - 2.0 | 2.8 | 3.0 | 3.2 V6 TFSI Engines
For alignment and adjustment of camshafts
and the replacement of timing chains etc.
Also re-setting engine timing when replacing the cylinder head gasket.

VAG Timing Tool Set
Audi A4 / A6 / A8 - 2.5 | 3.2 | 4.2 V6 FSI Engines
For alignment and adjustment of camshafts
and the replacement of timing chains etc.
Also re-setting engine timing when replacing the cylinder head gasket

VAG Timing Tool Set
for 1.8 / 2.0 FSI | TSI | TFSI Petrol Engines.
Camshaft Locking Block
Camshaft Aduster Sockets - 3/8in.Dr
Belt Tension Adjuster
Locking Pins
Pin Wrench
Tensioner Bolt.
For 2.0 FSI petrol engines 2003 onwards.

VAG Timing Tool Set
for 1.0 / 1.2 / 1.4 - MPI / TSI Petrol Engines
Suitable for 3 and Cylinder Engines.
Crankshaft Locking Bolt
Camshaft Adjusting Plate
Camshaft Sprocket Locking Tool
Tensioner Adjusting Wrench
Camshaft Adjusting Plate
Assembly Tool

VAG Timing Tool Set
for 1.2 / 1.4 TSI Petrol Engines
Essential tools for camshaft locking
crankshaft replacement and timing belt replacement
on VAG belt drive petrol engines including the 1.4 TSI ACT.
Applicable to Audi A1 | A3.
Seat lbiza | Leon | Toledo
Scoda Fabia and Octavia

VAG Timing Tool Set
for 1.0 / 1.2 / 1.4 TSI | TFSI EA211 Petrol Engines
1.2 TFSI : CJZA | CJZB
1.4 TFSI : CMBA | CXSA | CHPA
1.4 TGI : CPWA
1.4 TSI : Multi Fuel CPVA
1.4 Hybrid CRJA

VAG Camshaft Drive Tensioner Wrench
For adjusting the Camshaft drive belt tensioner on
VAG Vehicles with 1.0 / 1.2 / 1.4 turbo charged engines.
Applicable to :
Audi - A1 / A3
Seat - Mii / Leon
Skoda - Octavia / Citigo
Volkswagen - Up / Golf V11
OEM Code : T10499

VAG Timing Tool Set
for VAG 1.4 TFSI and 1.6 FSI Petrol Engines
To check and adjust camshaft timing
required when replacing timing chains.
With Camshaft Locking Tool
and Setting Gauge Holder.

VAG Timing Tools
for 1.2 TSI / TFSI Petrol Engines
Camshaft and Crankshaft Locking / Setting Tools
For adjusting the timing and replacement of the timing chain
or renewing the cylinder head gasket.
For Volkswagen 1.2 TSI / TFSI engines in -
Audi - Al | A3
VW - Beetle / Caddy / Golf / Jetta / Polo / Touran

VAG Timing Tool Set
for 1.2 / 1.4 / 1.6 FSI | TSI | TFSI Petrol Engines
on the VAG range of vehicles from 2003 to 2015.
Set Includes :
Dial Test Indicator and adaptor for an accurate TDC.
Crankshaft Locking Pin
Camshaft Locking and Alignment Tools
Gauge / Tension and Alignment Pins

VAG Timing Tool Set
for 1.8 / 2.0 TSI / TFSI 4-cylinder Petrol Engines.
For correcting camshaft and crankshaft timing position.
Applicable to :
the EA888 Series Engine on -
1.8 R4 16V TSI / TFSI
2.0 R4 16V TSI / TFSI

VAG Timing Tool Set
for 1.2 / 1.4 / 1.6 / 2.0 / 2.4 / 3.2 FSI / TFSI Petrol Engines
Allows the installation and removal of the camshaft / timing belt
when checking and adjusting the camshaft timing.
Cam Belt / Chain Locking Pins
Camshaft Alignment / Locking Tools
Crankshaft Alignment & Locking Pins
Dial Gauge and TDC Indicator
Tensioner / Pulley Bolt & Locking Pins
Timing Belt Spanner Wrench

VAG Timing Tool Set
for 1.8 / 2.0 TFSI Chain Drive Petrol Engines
Essential tools required to remove the camshaft adjuster valves
and a useful crankshaft pulley holding tool.
Some applications and repair operations will require additional tools.
Applicable to : Audi | Seat | Skoda | VW

VAG Timing Tool Set
for 2.9 / 3.0 TFSI EA839 Petrol Engines
Designed to fix the camshafts in position
when removing and installing the camshaft timing chains.
Applicable to : Audi / Porsche / VW - 2016 onwards.
OEM numbers : T40331 | T90000 | T90001 | T90002.

VAG Timing Chain Tension Lever
for 1.8 / 2.0 TFSi Petrol Engines
Allows the timing chain tensioner to be retracted and locked
without removing the lower timing cover.
Applicable to TFSI engines from 2007 onwards
on Audi / Seat / Skoda / Volkswagen models.
OEM Code : T40243

VAG Timing Tool Set
for Porsche 911 Engines
for checking and adjusting timing on Porsche 911 - 996 / 997.
Camshaft Holding Tool for engine M96 / 03.
Camshaft Locking Tool for engines M96 / 03 and M97 / 01.
Locking Pins for engines M96 / 03 and M97 / 01.

VAG Timing Tool Set
for 2.5 / 2.7 / 3.2 / 3.4 / 3.6 Porsche 911 / Boxster Engines
Allows engine timing when performing valve-train service.
With - TDC Alignment Pin
Camshaft Lock & Alignment Tools
Camshaft Holding Tools
Connecting Rod Centring Mandrel
Piston Pin Driver and Extensions
Porsche Boxster : 2.5 / 2.7 / 3.2 - 986 / 987 1998 - 2000
Porsche 911 : 3.4 / 3.6 - 996 / 997 2002 onwards

VAG Timing Tool Set
for Porsche Cayenne and Panamera V8 Engines
Also Porsche Cayenne utilizing the M97/01 V8 engine.
For camshaft timing on Direct Fuel Injection /
Turbo and Normally-aspirated Engines
Allows TDC Timing during servicing the
Camshafts / Cylinder Head / Timing Chain
or Variable Valve-timing Cam Phasers.
Cayenne V8 up to 2007 and Cayenne and Panamera 2008 onwards

VAG Timing Tool Set
for Porsche Macan 3.0S / 3.6 Turbo Engines
For changing the timing chain
or replacing the cylinder head gasket.
Engine codes : MCT.M / MCT.L
Ideal for use with Porsche Cayenne Timing Kit - CT3767
OEM Code : 9861
